Orion Fans
8005184160 OD9238-48HBIP68, DC Fans DC Axial Fan, 92x92x38mm, 48VDC, 100CFM, 12W, 0.25A, 56dBA, Ball, Wire, IP68 Hirschmann
5160,00 ₽
Описание
Вентилятор осевой, квадратный, 48 В постоянного тока — шарик 92 мм, высота 92 мм, 2 провода
| Вес, г | 199 |
| Потребляемая мощность, Вт | 12 |
| Fan Type | Tubeaxial |
| Series | OD9238-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 92×92 |
| Рабочее напряжение,В | 48 |
| Толщина,мм | 38 |
| Питание | 2pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart |
| IP Rating | IP68 |
| Noise | 56.0dB |
| Power Rating | 12W |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 70000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Operating Temperature | 14 ~ 158В°F(-10 ~ 70В°C) |
| Size / Dimension | Square-92mm L x 92mm H |
| Termination | 2 Wire Leads |
| Weight | 0.441 lb(200.00 g) |
| Width | 38.00mm |
| Current Rating (Amps) | 0.250A |
| Ingress Protection | IP68-Dust Tight, Waterproof |
| Static Pressure | 0.7 in H2O(174.4 Pa) |
| Bearing Type | Ball Bearing |
| Current Rating | 250mA |
| Air Flow — CFM | 100CFM |
| External Depth | 38mm |
| Fan Frame Size | 92mm |
| Fan Frame Type | Square |
| Noise Rating | 56.2dBA |
| Power Connection Type | 2 Lead Wires |
| Product Range | OD9238-IP68 Series |
| Rated Speed | 4500rpm |
| Частота вращения,об./мин. | 4500 |
| Производительность,м.куб./мин. | 100 |
| Шум, дБA | 56 |
| Supply Voltage VDC | 48V |
Детали
| Бренд | Orion Fans |
|---|
