EBM-PAPST
8005751766 4312NH3, Fan Tubeaxial 12VDC Square — 119mm L x 119mm H Ball 167.0 CFM (4.68m³/min) 2 Wire Leads Hirschmann
11020,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 119mm L x 119mm H Ball 167.0 CFM (4.68mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 12 |
| Fan Type | Tubeaxial |
| Series | 4300N-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 119×119 |
| Рабочее напряжение,В | 12 |
| Питание | 2pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| RoHS Status | ROHS3 Compliant |
| Noise | 55.0dB(A) |
| Lifetime @ Temp. | 45000 Hrs @ 40В°C |
| Material — Blade | Polyamide(PA), Nylon, Fiberglass Reinforced |
| Material — Frame | Polybutylene Terephthalate(PBT), Fiberglass Reinf |
| Operating Temperature | -4 ~ 167В°F(-20 ~ 75В°C) |
| Size / Dimension | Square-119mm L x 119mm H |
| Termination | 2 Wire Leads |
| Weight | 0.553 lb(250.84 g) |
| Width | 32.00mm |
| Power consumption | 12 W |
| Rated voltage | 12 V |
| Sound pressure level | 55 db |
| speed | 4050 1/min |
| Type of bearing | ball bearing |
| Version | DC axial fan |
| Volume flow | 285 m³/h |
| Частота вращения,об./мин. | 4050 |
| Производительность,м.куб./мин. | 167 |
| Voltage Range | 7 ~ 13.2VDC |
Детали
| Бренд | EBM-PAPST |
|---|
