Orion Fans
8005880635 OD9238-12HBVXC, FAN AXIAL 92.5X38MM 12VDC WIRE Hirschmann
4330,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 92.5mm L x 92.5mm H Ball 135.0 CFM (3.78mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 16 |
| Fan Type | Tubeaxial |
| Mounting | Flange Mount |
| Noise Level | 58 dB |
| Series | OD9238 VA-> |
| Special Features | High Static Pressure|High Speed |
| Тип подшипника | Ball |
| Размеры рамы,мм | 92.5×92.5 |
| Рабочее напряжение,В | 12 |
| Толщина,мм | 38 |
| Питание | 2pin |
| Product Category | DC Fan |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart |
| Noise | 58.0dB |
| Power Rating | 24W |
| Type | Axial |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 50000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT), Fiberglass Reinf |
| Material — Frame | Polybutylene Terephthalate(PBT), Fiberglass Reinf |
| Operating Temperature | 14 ~ 158В°F(-10 ~ 70В°C) |
| Size / Dimension | Square-92.5mm L x 92.5mm H |
| Termination | 2 Wire Leads |
| Width | 38.00mm |
| Category | DC Fan |
| COO | CN |
| Housing Material | Plastic |
| Maximum Airflow | 135 CFM |
| RoHS | Yes |
| Supplier Standard Pack | 1 |
| Voltage Rating | 12 V |
| Единица измерения | шт |
| Current Rating (Amps) | 1.3A |
| Static Pressure | 0.74 in H2O(184.3 Pa) |
| Bearing Type | Ball Bearing |
| Current Rating | 2A |
| Air Flow — CFM | 125CFM |
| External Depth | 38mm |
| Fan Frame Size | 92mm |
| Fan Frame Type | Square |
| Noise Rating | 62dBA |
| Power Connection Type | 2 Lead Wires |
| Product Range | OD9238-VXC Series |
| Rated Speed | 5400rpm |
| Частота вращения,об./мин. | 5400 |
| Производительность,м.куб./мин. | 135 |
| Шум, дБA | 58.5 |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| Video File | Vane Axial Self Levitating from Orion Fans |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Pressure | 0.74inH2O |
| Minimum Operating Temperature (°C) | -10 |
| Protection | Auto Restart|Polarity |
| Shape | Square |
| Size (mm) | 92.5 X 92.5 X 38 |
| Supply Voltage VDC | 12V |
Детали
| Бренд | Orion Fans |
|---|
