Mechatronics
8005961725 E1225E12B-FSR, Fan Tubeaxial 12VDC Square — 120mm L x 120mm H Ball 93.0 CFM (2.60m³/min) 2 Wire Leads Hirschmann
3740,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 120mm L x 120mm H Ball 93.0 CFM (2.60mВі/min) 2 Wire Leads
| Вес, г | 200 |
| Fan Type | Tubeaxial |
| Series | E1225-> |
| Тип подшипника | Ball |
| Рабочее напряжение,В | 12 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| RoHS Status | RoHS Compliant |
| Features | Thermal Overload Protector(TOP) |
| Noise | 44.0dB(A) |
| Approval Agency | CE, cUL, TUV, UL |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Size / Dimension | Square-120mm L x 120mm H |
| Termination | 2 Wire Leads |
| Weight | 0.434 lb(196.86 g) |
| Width | 25.00mm |
| COO | ID |
| RoHS | Yes |
| Supplier Standard Pack | 1 |
| Единица измерения | шт |
| Current Rating (Amps) | 0.580A |
| Static Pressure | 0.28 in H2O(69.7 Pa) |
| Частота вращения,об./мин. | 3000 |
| Производительность,м.куб./мин. | 93 |
Детали
| Бренд | Mechatronics |
|---|
