CUI Inc
8006885274 CFM-A225-13-22, FAN AXIAL 120X25.4MM 12VDC WIRE Hirschmann
4470,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 120mm L x 120mm H Ball 126.9 CFM (3.55mВі/min) 4 Wire Leads
| Потребляемая мощность, Вт | 9.48 |
| Fan Type | Tubeaxial |
| Series | CFM-120-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 92×92 |
| Рабочее напряжение,В | 12 |
| Толщина,мм | 38 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Tray |
| RoHS Status | RoHS Compliant |
| Features | Auto Restart, PWM Control, Speed Sensor(Tach) |
| Noise | 53.5dB(A) |
| Approval Agency | CE, cURus, TUV |
| Lifetime @ Temp. | 70000 Hrs @ 45В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Operating Temperature | 14 ~ 158В°F(-10 ~ 70В°C) |
| Size / Dimension | Square-120mm L x 120mm H |
| Termination | 4 Wire Leads |
| Weight | 0.419 lb(190.06 g) |
| Width | 25.40mm |
| Current Rating (Amps) | 0.590A |
| Static Pressure | 0.49 in H2O(122.1 Pa) |
| Частота вращения,об./мин. | 4100 |
| Производительность,м.куб./мин. | 126.9 |
| Video File | CUI Devices CFM Series DC Axial Fans | Digi-Key Da |
| Voltage Range | 6 ~ 13.8VDC |
Детали
| Бренд | CUI Inc |
|---|
