Sanyo Denki
8018971585 Вентилятор Sanyo Denki San Ace B97 109BD24FC2 (EP 1107089) 24V DC 0.14A 76X30 3pin () Hirschmann
4280,00 ₽
Описание
Fan Blower 24VDC Square/Rounded — 76mm L x 75.5mm H Ball 10.9 CFM (0.305mВі/min) 3 Wire Leads
| Вес, г | 400 |
| Fan Type | Blower |
| Series | San Ace B76-> |
| Размеры рамы,мм | 76×76 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 30 |
| Питание | 3pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6560 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Box |
| RoHS Status | ROHS3 Compliant |
| Features | Locked Rotor Protection, Speed Sensor(Tach) |
| Noise | 37.0dB(A) |
| Approval Agency | CSA, TUV, UL |
| Lifetime @ Temp. | 40000 Hrs @ 60В°C |
| Material — Blade | Plastic |
| Material — Frame | Plastic |
| Operating Temperature | -4 ~ 158В°F(-20 ~ 70В°C) |
| Size / Dimension | Square/Rounded-76mm L x 75.5mm H |
| Termination | 3 Wire Leads |
| Weight | 0.222 lb(100.7 g) |
| Width | 30.00mm |
| Current Rating (Amps) | 0.140A |
| Static Pressure | 0.394 in H2O(98.1 Pa) |
| Ток,А | 0.14 |
| Video File | Summary of SanAce Cooling SystemsSanAce Server Coo |
| Voltage Range | 20.4 ~ 27.6VDC |
Детали
| Бренд | Sanyo Denki |
|---|
