Sanyo Denki
8070524025 109P0424H302,DC Axial Fan, 24 V, Square, 40 mm, 28 mm, Ball Bearing, 11.3 CFM Hirschmann
6200,00 ₽
Описание
Our DC cooling fans have features such as high airflow, high reliability, and low noise. They can be used in a wide-ranging applications including servers and ICT equipment.
| Вес, г | 45 |
| Потребляемая мощность, Вт | 2.28 |
| Air Flow | 11.3cfm |
| Fan Type | Tubeaxial |
| Series | 9P Type |
| Тип подшипника | Качения |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 28 |
| Питание | 3pin |
| Factory Pack Quantity | 126 |
| Packaging | Bulk |
| ECCN | 4A994 |
| HTSUS | 8414596590 |
| RoHS Status | RoHS Compliant |
| Features | Locked Rotor Sensor |
| Airflow | 11.3 CFM(0.32 m3/min) |
| Current Type | DC |
| Noise | 37 dBA |
| Operating Supply Voltage | 24 VDC |
| Power Rating | 2.28 W |
| Termination Style | Wire Leads-2 |
| Type | Axial |
| Approval Agency | CSA, TUV, UL |
| Operating Temperature | -4 ~ 158°F(-20 ~ 70°C) |
| Termination | 2 Wire Leads |
| Width | 40mm |
| Housing Material | Plastic |
| speed | 8700 RPM |
| Bearing Type | Ball |
| Pressure Type | 10 mmAq |
| Ток,А | 95 |
| Производительность,м.куб./мин. | 11.3 |
| Шум, дБA | 37 |
| Power (Watts) | 2.28 W |
| RPM | 8700 RPM |
| Voltage — Rated | 24VDC |
| Tradename | San Ace 40 |
| AC or DC Operation | DC |
| Direction of Curve | Forward |
| Termination Type | Lead Wire |
| Compliance | CSA; TUV; UL |
Детали
| Бренд | Sanyo Denki |
|---|
