Comair Rotron
8005842880 17000537A, Fan Tubeaxial 100 ~ 240VAC Square — 120mm L x 120mm H Ball 92.0 CFM (2.58m³/min) 2 Terminals Hirschmann
9160,00 ₽
Описание
Fan Tubeaxial 100 ~ 240VAC Square — 120mm L x 120mm H Ball 92.0 CFM (2.58mВі/min) 2 Terminals
| Потребляемая мощность, Вт | 5.5 |
| Fan Type | Tubeaxial |
| Тип подшипника | Ball |
| Рабочее напряжение,В | 100 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart, Electronic Commutation(EC) |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp. | Varies Based on Temperature |
| Material — Blade | Polybutylene Terephthalate(PBT), Fiberglass Reinf |
| Material — Frame | Magnesium Alloy |
| Operating Temperature | -4 ~ 158В°F(-20 ~ 70В°C) |
| Size / Dimension | Square-120mm L x 120mm H |
| Termination | 2 Terminals |
| Weight | 0.498 lb(225.89 g) |
| Width | 25.00mm |
| Current Rating (Amps) | 0.700A |
| Static Pressure | 0.3 in H2O(74.7 Pa) |
| Частота вращения,об./мин. | 3200 |
| Производительность,м.куб./мин. | 92 |
| Шум, дБA | 47 |
| Voltage Range | 90 ~ 264VAC |
Детали
| Бренд | Comair Rotron |
|---|
