Sanyo Denki
8002934653 9BMC24P2G001, San Ace B97 Series Centrifugal Fan, 24 V dc, 65.3cfm, DC Operation, 97 x 97 x 33mm Hirschmann
18140,00 ₽
Описание
High Air Flow & Static Pressure Max. air flow: 1.85m3/min Max. static pressure: 1.950Pa High cooling performance even in equipment with high system impedance
| Вес, г | 230 |
| Air Flow | 65.3cfm |
| Mounting | Flange Mount |
| Noise Level | 69dB(A) |
| Series | 9BMC Type |
| Supply Voltage | 24 V dc |
| Brand | Sanyo Denki |
| Manufacturer | Sanyo Denki |
| Product Category | DC Blower |
| Product Type | Blowers |
| Subcategory | Fans, Blowers & Accessories |
| Features | Tachometer, PWM |
| Airflow | 65.3 CFM(1.85 m3/min) |
| Current Type | DC |
| Depth | 97 mm |
| Factory Pack Quantity: Factory Pack Quantity | 30 |
| Noise | 69 DBA |
| Operating Supply Voltage | 24 VDC |
| Power Rating | 74.4 W |
| Termination Style | Wire Leads |
| Type | Centrifugal |
| Width | 97mm |
| Housing Material | Plastic |
| speed | 8200 RPM |
| Static Pressure | 1950Pa |
| Pressure Type | 7.83 in H2O |
| Blower Type | Blower |
| Tradename | San Ace B97 |
| AC or DC Operation | DC |
| Maximum Current | 3.1A |
| Fan Speed | 8200rpm |
| Direction of Curve | Backward |
| Mounting hole diameter | 4.5mm |
| Horizontal Hole Spacing | 71mm |
| Mounting Hole Spacing | 71x71mm |
| Sensor Type | PWM |
| Vertical Hole Spacing | 71mm |
| Termination Type | Lead Wire |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Pressure | 7.83inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Protection | Polarity |
| Size (Metric) (mm) | 97.1 X 96.5 X 33 |
| Voltage Rating (V) | 24 |
| Power Rating (W) | 74.4 |
| Nominal Speed (r/min) | 8200 |
| Maximum Airflow (CFM) | 65.3 |
| Noise Level (dB) | 69 |
| Bearings | Ball |
| Line Current (A) | 3.1 |
| Operating Input Voltage Range (V) | 21.6 to 26.4 |
| Inlet Diameter | 56mm |
Детали
| Бренд | Sanyo Denki |
|---|
