Sanyo Denki
8005415060 109BD24HC2, Blowers & Centrifugal Fans DC Blower, 76x30mm, 24VDC, Tachometer Hirschmann
7350,00 ₽
Описание
Fan Blower 24VDC Square/Rounded — 76mm L x 75.5mm H Ball 12.7 CFM (0.356mВі/min) 3 Wire Leads
| Вес, г | 99 |
| Air Flow | 12.7cfm |
| Fan Type | Blower |
| Series | San Ace B76 9BD |
| Тип подшипника | Ball |
| Размеры рамы,мм | 76×76 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 30 |
| Питание | 3pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6560 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Box |
| RoHS Status | ROHS3 Compliant |
| Features | Locked Rotor Protection, Speed Sensor(Tach) |
| Noise | 41.5dB(A) |
| Approval Agency | CSA, TUV, UL |
| Lifetime @ Temp. | 40000 Hrs @ 60В°C |
| Material — Blade | Plastic |
| Material — Frame | Plastic |
| Operating Temperature | -4 ~ 140В°F(-20 ~ 60В°C) |
| Size / Dimension | Square/Rounded-76mm L x 75.5mm H |
| Termination | 3 Wire Leads |
| Weight | 0.222 lb(100.7 g) |
| Width | 76 Dia.mm |
| Current Rating (Amps) | 0.170A |
| Static Pressure | 151.9Pa |
| Ток,А | 170 |
| Blower Type | Blower |
| Производительность,м.куб./мин. | 12.7 |
| Шум, дБA | 41.5 |
| AC or DC Operation | DC |
| Direction of Curve | Forward |
| Mounting hole diameter | 4.5mm |
| Horizontal Hole Spacing | 45.7mm |
| Mounting Hole Spacing | 45.7×67.1mm |
| Sensor Type | Pulse |
| Vertical Hole Spacing | 67.1mm |
| Termination Type | Lead Wire |
| Video File | Summary of SanAce Cooling SystemsSanAce Server Coo |
| Voltage Range | 20.4 ~ 27.6VDC |
Детали
| Бренд | Sanyo Denki |
|---|
