Orion Fans
8005761880 OD180APL-24MB, Fan Tubeaxial 24VDC Square — 180mm L x 180mm H Ball 375.0 CFM (10.50m³/min) 2 Wire Leads Hirschmann
27410,00 ₽
Описание
Fan Tubeaxial 24VDC Square — 180mm L x 180mm H Ball 375.0 CFM (10.50mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 24 |
| Fan Type | Tubeaxial |
| Series | OD180APL |
| Тип подшипника | Ball |
| Размеры рамы,мм | 80×80 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 65 |
| Питание | 2pin |
| Brand | Orion Fans |
| Manufacturer | Orion Fans |
| Product Category | DC Fans |
| Product Type | DC Fans |
| Subcategory | Fans, Blowers & Accessories |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart, Polarity Protection |
| Current Type | DC |
| Factory Pack Quantity: Factory Pack Quantity | 1 |
| Noise | 53.0dB |
| Power Rating | 24W |
| Termination Style | Wire Leads-2 |
| Type | Axial |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 60000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT), Fiberglass Reinf |
| Material — Frame | Aluminum |
| Operating Temperature | -4 ~ 149В°F(-20 ~ 65В°C) |
| Size / Dimension | Square-180mm L x 180mm H |
| Termination | 2 Wire Leads |
| Width | 65.00mm |
| Housing Material | Aluminum |
| Current Rating (Amps) | 0.970A |
| Static Pressure | 0.7 in H2O(174.4 Pa) |
| Bearing Type | Ball Bearing |
| Current Rating | 970mA |
| Air Flow — CFM | 375CFM |
| External Depth | 65mm |
| Fan Frame Size | 180mm |
| Fan Frame Type | Square |
| Noise Rating | 53dBA |
| Power Connection Type | 2 Lead Wires |
| Product Range | OD180APL Series |
| Rated Speed | 2800rpm |
| Частота вращения,об./мин. | 2800 |
| Производительность,м.куб./мин. | 375 |
| Шум, дБA | 53 |
| Supply Voltage VDC | 24V |
Детали
| Бренд | Orion Fans |
|---|
