Orion Fans
8005764517 OD172SAP-48HBIP68, Fan Tubeaxial 48VDC Rectangular/Rounded — 172mm L x 150mm H Ball 235.0 CFM (6.58m³/min) 2 Wire Leads Hirschmann
23640,00 ₽
Описание
Fan Tubeaxial 48VDC Rectangular/Rounded — 172mm L x 150mm H Ball 235.0 CFM (6.58mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 23.5 |
| Fan Type | Tubeaxial |
| Series | OD172SAP-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 172×150 |
| Рабочее напряжение,В | 48 |
| Толщина,мм | 51 |
| Питание | 2pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart |
| IP Rating | IP68 |
| Noise | 52.0dB |
| Power Rating | 23.5W |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 90000 Hrs @ 35В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Operating Temperature | 5 ~ 149В°F(-15 ~ 65В°C) |
| Size / Dimension | Rectangular/Rounded-172mm L x 150mm H |
| Termination | 2 Wire Leads |
| Weight | 1.8 lbs(816.5 g) |
| Width | 51.00mm |
| Current Rating (Amps) | 0.480A |
| Ingress Protection | IP68-Dust Tight, Waterproof |
| Static Pressure | 0.79 in H2O(196.8 Pa) |
| Bearing Type | Ball Bearing |
| Current Rating | 480mA |
| Air Flow — CFM | 235CFM |
| External Depth | 51mm |
| Fan Frame Size | 172mm |
| Fan Frame Type | Rectangular with Rounded Ends |
| Noise Rating | 52dBA |
| Power Connection Type | 2 Lead Wires |
| Product Range | OD172SAP Series |
| Rated Speed | 3300rpm |
| Частота вращения,об./мин. | 3300 |
| Производительность,м.куб./мин. | 235 |
| Шум, дБA | 52 |
| Supply Voltage VDC | 48V |
Детали
| Бренд | Orion Fans |
|---|
