Mechatronics
8005766189 G6015H24B-AGR-EM, Fan Tubeaxial 24VDC Square — 60mm L x 60mm H Ball 18.0 CFM (0.504m³/min) 2 Wire Leads Hirschmann
4080,00 ₽
Описание
Fan Tubeaxial 24VDC Square — 60mm L x 60mm H Ball 18.0 CFM (0.504mВі/min) 2 Wire Leads
| Fan Type | Tubeaxial |
| Series | G6015-G-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 60×60 |
| Рабочее напряжение,В | 24 |
| Питание | 2pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| RoHS Status | RoHS Compliant |
| Features | Thermal Overload Protector(TOP) |
| Noise | 33.0dB(A) |
| Approval Agency | CE, cUL, TUV, UL |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Size / Dimension | Square-60mm L x 60mm H |
| Termination | 2 Wire Leads |
| Weight | 0.111 lb(50.35 g) |
| Width | 15.00mm |
| Current Rating (Amps) | 0.950A |
| Ingress Protection | IP57-Dust Protected, Waterproof |
| Static Pressure | 0.21 in H2O(52.3 Pa) |
| Частота вращения,об./мин. | 4600 |
| Производительность,м.куб./мин. | 18 |
Детали
| Бренд | Mechatronics |
|---|
