Sunon
8005889065 ME92251V2-000U-F99, Fan Tubeaxial 12VDC Square — 92mm L x 92mm H Vapo-Bearing™ 45.0 CFM (1.26m³/min) 3 Wire Leads Hirschmann
1440,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 92mm L x 92mm H Vapo-Bearingв„ў 45.0 CFM (1.26mВі/min) 3 Wire Leads
| Потребляемая мощность, Вт | 1.6 |
| Fan Type | Tubeaxial |
| Series | MagLevВ® ME-> |
| Тип подшипника | Vapo-Bearingв(ў |
| Размеры рамы,мм | 92×92 |
| Рабочее напряжение,В | 12 |
| Питание | 3pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart, Locked Rotor Sensor |
| Noise | 32.0dB(A) |
| Approval Agency | CUR, TUV, UL |
| Lifetime @ Temp. | 70000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Operating Temperature | 14 ~ 158В°F(-10 ~ 70В°C) |
| Size / Dimension | Square-92mm L x 92mm H |
| Termination | 3 Wire Leads |
| Weight | 0.212 lb(96.16 g) |
| Width | 25.00mm |
| Current Rating (Amps) | 0.135A |
| Static Pressure | 0.13 in H2O(32.4 Pa) |
| Частота вращения,об./мин. | 2700 |
| Производительность,м.куб./мин. | 45 |
| Video File | Sunon DR MaglevSunon Demonstrates the Autorestart |
| Voltage Range | 4.5 ~ 13.8VDC |
| Environmental Information | http://www.sunon.com/uFiles/file/01_about%20sunon/ |
Детали
| Бренд | Sunon |
|---|
