Sanyo Denki
8006025796 9GV0412J301, Fan Tubeaxial 12VDC Square — 40mm L x 40mm H Ball 24.0 CFM (0.672m³/min) 3 Wire Leads Hirschmann
3430,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 40mm L x 40mm H Ball 24.0 CFM (0.672mВі/min) 3 Wire Leads
| Напряжение питания | 12 В пост. тока |
| Air Flow | 24.0 CFM (0.672mВі/min) |
| Fan Type | Tubeaxial |
| Noise Level | 54дБ |
| Series | San Ace 40 -> |
| Высота | 40мм |
| Размеры рамы,мм | 40×40 |
| Рабочее напряжение,В | 12 |
| Питание | 3pin |
| Brand | Sanyo Denki |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Package | Box |
| RoHS Status | ROHS3 Compliant |
| Features | Speed Sensor (Tach) |
| Глубина | 28мм |
| Noise | 55.0dB(A) |
| Approval Agency | CSA, TUV, UL |
| Lifetime @ Temp. | 40000 Hrs @ 60В°C |
| Material — Blade | Plastic |
| Material — Frame | Plastic |
| Operating Temperature | -4 ~ 140В°F (-20 ~ 60В°C) |
| Size / Dimension | Square — 40mm L x 40mm H |
| Termination | 3 Wire Leads |
| Weight | 0.111 lb (50.35 g) |
| Width | 28.00mm |
| Power consumption | 7.2W |
| Current Rating (Amps) | 0.600A |
| Static Pressure | 1.325 in H2O (330.0 Pa) |
| Bearing Type | Ball |
| Power (Watts) | 7.2W |
| RPM | 14700 RPM |
| Voltage — Rated | 12VDC |
| AC or DC Operation | постоянный ток |
| Maximum Current | 0 → 600mA |
| Fan Speed | 14700rpm |
| Video File | Summary of SanAce Cooling SystemsSanAce Server Coo |
| Voltage Range | 7 ~ 13.2VDC |
| Dimensions | 40 X 40 X 28mm |
Детали
| Бренд | Sanyo Denki |
|---|
