EBM-PAPST
8006100297 W2G115-AD15-13, Fan Tubeaxial 12VDC Square — 127mm L x 127mm H Ball 118.0 CFM (3.30m³/min) 2 Terminals Hirschmann
16830,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 127mm L x 127mm H Ball 118.0 CFM (3.30mВі/min) 2 Terminals
| Потребляемая мощность, Вт | 4.5 |
| Fan Type | Tubeaxial |
| Noise Level | 44 dB |
| Series | W2G115-> |
| Special Features | None |
| Тип подшипника | Ball |
| Размеры рамы,мм | 127×127 |
| Рабочее напряжение,В | 12 |
| Factory Pack Quantity | 1 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| RoHS Status | ROHS3 Compliant |
| Features | Locked Rotor Sensor |
| Airflow | 118 CFM(3.3 m3/min) |
| Current Type | DC |
| IP Rating | IP22 |
| Noise | 44.0dB(A) |
| Operating Supply Voltage | 12 VDC |
| Power Rating | 4.5 W |
| Termination Style | Quick Connect Terminal |
| Type | Tubeaxial |
| Approval Agency | CSA, UL, VDE |
| Material — Blade | Steel |
| Material — Frame | Aluminum |
| Operating Temperature | 72 °C |
| Size / Dimension | Square-127mm L x 127mm H |
| Termination | 2 Terminals |
| Weight | 1.2 lbs(544.3 g) |
| Width | 38.00mm |
| Category | DC Fan |
| COO | DE |
| Housing Material | Aluminum |
| Maximum Airflow | 118 CFM |
| RoHS | Yes |
| Supplier Standard Pack | 1 |
| Voltage Rating | 12 V |
| Единица измерения | шт |
| speed | 2800 RPM |
| Bearing Type | Ball |
| Частота вращения,об./мин. | 2800 |
| Производительность,м.куб./мин. | 118 |
| Voltage Range | 8 ~ 16VDC |
Детали
| Бренд | EBM-PAPST |
|---|
