8006561336 G8015L05B-RGR, Fan Tubeaxial 5VDC Square — 80mm L x 80mm H Ball 29.0 CFM (0.812m³/min) 2 Wire Leads Hirschmann
2780,00 ₽
Описание
Fan Tubeaxial 5VDC Square — 80mm L x 80mm H Ball 29.0 CFM (0.812mВі/min) 2 Wire Leads
| Fan Type | Tubeaxial |
| Series | G8015-G-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 80×80 |
| Рабочее напряжение,В | 5 |
| Питание | 2pin |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Bulk |
| RoHS Status | RoHS Compliant |
| Features | Thermal Overload Protector(TOP) |
| Noise | 31.0dB(A) |
| Approval Agency | CE, cUL, TUV, UL |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Size / Dimension | Square-80mm L x 80mm H |
| Termination | 2 Wire Leads |
| Weight | 0.128 lb(58.06 g) |
| Width | 15.30mm |
| Current Rating (Amps) | 0.280A |
| Static Pressure | 0.11 in H2O(27.4 Pa) |
| Частота вращения,об./мин. | 3200 |
| Производительность,м.куб./мин. | 29 |
Детали
| Бренд | Mechatronics |
|---|
