Orion Fans
8006934126 OD172SAP-24HBXCIP69K, Fan Tubeaxial 24VDC Rectangular/Rounded — 172mm L x 152mm H Ball 323.0 CFM (9.04m³/min) 2 Wire Leads Hirschmann
21900,00 ₽
Описание
Fan Tubeaxial 24VDC Rectangular/Rounded — 172mm L x 152mm H Ball 323.0 CFM (9.04mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 50.4 |
| Fan Type | Tubeaxial |
| Series | OD172SAP XC-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 172×152 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 51 |
| Питание | 2pin |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Package | Bulk |
| RoHS Status | ROHS3 Compliant |
| Features | Auto Restart |
| Noise | 63.5dB |
| Approval Agency | CE, cURus, TUV, UR |
| Lifetime @ Temp. | 90000 Hrs @ 35В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Aluminum |
| Operating Temperature | -4 ~ 149В°F(-20 ~ 65В°C) |
| Size / Dimension | Rectangular/Rounded-172mm L x 152mm H |
| Termination | 2 Wire Leads |
| Weight | 1.3 lbs(600.0 g) |
| Width | 51.60mm |
| Current Rating (Amps) | 2.10A |
| Ingress Protection | IP69K-Dust Tight, Water Resistant, Waterproof |
| Static Pressure | 1.06 in H2O(264.0 Pa) |
| Частота вращения,об./мин. | 4400 |
| Производительность,м.куб./мин. | 323 |
Детали
| Бренд | Orion Fans |
|---|
