Delta Electonics
8006984860 ASB02512VHA-A76N, Fan Tubeaxial 12VDC Square — 25mm L x 25mm H Sleeve 3.4 CFM (0.095m³/min) 3 Wire Leads Hirschmann
1430,00 ₽
Описание
Fan Tubeaxial 12VDC Square — 25mm L x 25mm H Sleeve 3.4 CFM (0.095mВі/min) 3 Wire Leads
| Вес, г | 147 |
| Потребляемая мощность, Вт | 600 |
| Air Flow | 3.4 CFM(0.095mВі/min) |
| Fan Type | Tubeaxial |
| Series | ASB |
| Тип подшипника | Sleeve |
| Размеры рамы,мм | 25×25 |
| Рабочее напряжение,В | 12 |
| Толщина,мм | 10 |
| Питание | 3pin |
| Brand | Delta Electronics |
| Manufacturer | Delta Electronics |
| Product Category | DC Fans |
| Product Type | DC Fans |
| Subcategory | Fans, Blowers & Accessories |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Features | Locked Rotor Sensor |
| Current Type | DC |
| Factory Pack Quantity: Factory Pack Quantity | 1440 |
| Noise | 27.0dB(A) |
| Termination Style | Wire Leads-3 |
| Type | Tubeaxial |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 30000 Hrs @ 40В°C |
| Material — Blade | Plastic |
| Material — Frame | Plastic |
| Operating Temperature | 14 ~ 167В°F(-10 ~ 75В°C) |
| Size / Dimension | Square-25mm L x 25mm H |
| Termination | 3 Wire Leads |
| Weight | 0.014 lb(6.35 g) |
| Width | 10.00mm |
| Housing Material | Plastic |
| Current Rating (Amps) | 0.050A |
| Ingress Protection | — |
| Static Pressure | 0.214 in H2O(53.3 Pa) |
| Bearing Type | Sleeve |
| Pressure Type | 0.214 in H2O |
| Частота вращения,об./мин. | 13000 |
| Производительность,м.куб./мин. | 3.4 |
| Шум, дБA | 27 |
| Power (Watts) | 600mW |
| RPM | 13000 RPM |
| Voltage — Rated | 12VDC |
| Part Status | Active |
| Линейка продукции | AFB Series |
| Voltage Range | 4.75 ~ 13.8VDC |
| Поток воздуха — куб.фут/мин | 3.35фут³/мин |
| Тип корпуса вентилятора | Square |
| Тип Подключения Питания | 3 Lead Wires, Sensor Output |
| Approvals | cURus, TUV |
Детали
| Бренд | Delta Electonics |
|---|
