Sanyo Denki
8007269281 9S0612P4H01, DC Fans DC Axial Fan, 60x60x25mm, 12VDC, Silent Series, Tachometer, PWM Hirschmann
2940,00 ₽
Описание
San Ace Fans with PWM Control Function
Sanyo Denki San Ace Fans with Pulse Width Modulation (PWM) Control Function enables designers to externally control the speed of fans. This beneficial design feature varies the duty cycles of PWM input signals between the control and grounding terminals. The PWM control allows fans to operate optimally in response to the device's heat level, lowering the noise and power consumption of systems. Sanyo Denki San Ace Fans with PWM Control Function offer precise control and the ability to control multiple fans.
| Вес, г | 56 |
| Потребляемая мощность, Вт | 1.32 |
| Air Flow | 34.8m³/h |
| Mounting | Flange Mount |
| Series | 9S Type |
| Special Features | Sensor |
| Тип подшипника | Ball |
| Размеры рамы,мм | 60×60 |
| Рабочее напряжение,В | 12 |
| Толщина,мм | 25 |
| Brand | Sanyo Denki |
| Manufacturer | Sanyo Denki |
| Packaging | Bulk |
| Product Category | DC Fan |
| Product Type | DC Fans |
| Subcategory | Fans, Blowers & Accessories |
| Features | Tachometer, PWM, Low Noise |
| Current Type | DC |
| Factory Pack Quantity: Factory Pack Quantity | 80 |
| Termination Style | Wire Leads-4 |
| Type | Axial |
| Width | 60mm |
| Housing Material | Plastic |
| Part # Aliases | 3019500 |
| Pressure Type | 4 mmAq |
| Ток,А | 110 |
| Частота вращения,об./мин. | 3900 |
| Производительность,м.куб./мин. | 20.5 |
| Шум, дБA | 24 |
| Tradename | San Ace 60 |
| AC or DC Operation | DC |
| Sensor Type | Pulse |
| Termination Type | Lead Wire |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 70 |
| Minimum Operating Temperature (°C) | -10 |
| Protection | Locking |
| Shape | Square |
| Compliance | CSA; TUV; UL |
| Size (Metric) (mm) | 60 X 60 X 25 |
| Operating Input Voltage Range (V) | 10.8 to 13.2 |
Детали
| Бренд | Sanyo Denki |
|---|
