Sanyo Denki
8007336162 Вентиляторы DC 9WP0612H401 Hirschmann
3050,00 ₽
Описание
DC Fans DC Fan, 60x25mm, 12VDC, 18.7CFM, 1.32W, 28dBA, 3800RPM, 40.2Pa, Splash Proof, Tachometer, IP68 Rated Вентилятор, Габарит 60X25, Напряжение 12VDC, Подшипник BALL, Скорость вращения 3800RPM, Уровень шума 28DB
| Вес, г | 110 |
| Air Flow | 18.7 CFM(0.524m³/min) |
| Fan Type | Tubeaxial |
| Series | 9WP |
| Рабочее напряжение,В | 12 |
| Толщина,мм | 25 |
| Brand | Sanyo Denki |
| Factory Pack Quantity | 80 |
| Manufacturer | Sanyo Denki |
| Packaging | Bulk |
| Product Category | DC Fans |
| Product | DC Fans |
| Features | Speed Sensor(Tach) |
| Airflow | 18.71 CFM |
| Current Type | DC |
| Noise | 28.0dB(A) |
| Operating Supply Voltage | 12 VDC |
| Termination Style | Wire Leads |
| Type | Splash Proof |
| Approval Agency | CSA, TUV, UL |
| Operating Temperature | -4 ~ 158°F(-20 ~ 70°C) |
| Termination | 3 Wire Leads |
| Width | 25 mm |
| Housing Material | Plastic |
| RoHS | Details |
| speed | 3800 RPM |
| Ingress Protection | IP68-Dust Tight, Waterproof |
| Static Pressure | 0.161 in H2O(40.2 Pa) |
| Bearing Type | Ball |
| Frame Dimensions — mm | 60 mm L x 25 mm W x 60 mm H |
| Part # Aliases | 2138742 96M1774 |
| Pressure Type | 4 mmAq |
| Производительность,м.куб./мин. | 18.7 |
| Шум, дБA | 28 |
| Power (Watts) | 1.32 W |
| RPM | 3800 RPM |
| Voltage — Rated | 12VDC |
| Tradename | San Ace |
| Height | 60 mm |
| Size | 60 mm |
| Length | 60 mm |
| Unit Weight | 3.174657 oz |
Детали
| Бренд | Sanyo Denki |
|---|
