Sanyo Denki
8007404809 9A0824H4011, DC Fans DC Axial Fan, 80x80x25mm, 24VDC, Ribless, Tachometer Hirschmann
3910,00 ₽
Описание
Our DC cooling fans have features such as high airflow, high reliability, and low noise. They can be used in a wide-ranging applications including servers and ICT equipment.
| Air Flow | 61.8m³/h |
| Fan Type | Tubeaxial |
| Mounting | Flange Mount |
| Noise Level | 29dB(A) |
| Supply Voltage | 24 V dc |
| Размеры рамы,мм | 80×80 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 25 |
| Product Category | DC Fan |
| Features | Locked Rotor Protection, Speed Sensor(Tach) |
| Noise | 29.0dB(A) |
| Type | Axial |
| Approval Agency | CSA, TUV, UL |
| Operating Temperature | -4 ~ 158°F(-20 ~ 70°C) |
| Termination | 3 Wire Leads |
| Width | 80mm |
| Power consumption | 1.68W |
| Static Pressure | 0.142 in H2O(35.4 Pa) |
| Bearing Type | Ball |
| Power (Watts) | 1.68 W |
| RPM | 2900 RPM |
| Voltage — Rated | 24VDC |
| AC or DC Operation | DC |
| Maximum Current | 70mA |
| Sensor Type | Pulse |
| Termination Type | Lead Wire |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | 4A994 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Pressure | 0.142inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Shape | Square |
| Size (Metric) (mm) | 80 X 80 X 25 |
| Voltage Rating (V) | 24 |
| Power Rating (W) | 1.68 |
| Nominal Speed (r/min) | 2900 |
| Maximum Airflow (CFM) | 36.4 |
| Noise Level (dB) | 29 |
| Bearings | Ball |
| Line Current (A) | 0.07 |
| Operating Input Voltage Range (V) | 12 to 27.6 |
Детали
| Бренд | Sanyo Denki |
|---|
