Sanyo Denki
8007962181 9G1224E102, DC Fans DC Axial Fan, 120x120x38mm, 24VDC, High Performance Hirschmann
6950,00 ₽
Описание
Fan Tubeaxial 24VDC Square — 119mm L x 119mm H Ball 118.0 CFM (3.30mВі/min) 2 Wire Leads
| Потребляемая мощность, Вт | 8.16 |
| Fan Type | Tubeaxial |
| Series | San Ace 120-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 120×120 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 38 |
| Manufacturer | SANYO DENKI |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| RoHS Status | ROHS3 Compliant |
| Noise | 46.0dB(A) |
| Approval Agency | CSA, TUV, UL |
| Lifetime @ Temp. | 40000 Hrs @ 60В°C |
| Material — Blade | Plastic |
| Material — Frame | Plastic |
| Operating Temperature | -4 ~ 158В°F(-20 ~ 70В°C) |
| Size / Dimension | Square-119mm L x 119mm H |
| Termination | 2 Wire Leads |
| Weight | 0.728 lb(330.22 g) |
| Width | 38.00mm |
| Enclosure material | plastic |
| Fan efficiency | 200.4m3/h |
| Impeller material | plastic |
| Kind of fan | axial |
| Leads | lead x2 |
| Type of fan | DC |
| Current Rating (Amps) | 0.340A |
| Static Pressure | 0.401 in H2O(100.0 Pa) |
| Current Rating | 0.34A |
| Шум, дБA | 46 |
| Fan dimensions | 120x120x38mm |
| Cable length | 0.3m |
| Video File | Summary of SanAce Cooling SystemsSanAce Server Coo |
| Voltage Range | 20.4 ~ 27.6VDC |
| Rotational rate/speed | 3100rpm |
| Kind of material | flame retardant |
| Min. insulation resistance | 10MΩ |
Детали
| Бренд | Sanyo Denki |
|---|
