Sanyo Denki
8008640290 109R0824S4011, Fan Tubeaxial 24VDC Square — 80mm L x 80mm H Ball 42.4 CFM (1.19m³/min) 3 Wire Leads Hirschmann
3770,00 ₽
Описание
Our DC cooling fans have features such as high airflow, high reliability, and low noise. They can be used in a wide-ranging applications including servers and ICT equipment.
| Air Flow | 72m³/h |
| Mounting | Flange Mount |
| Noise Level | 34dB(A) |
| Supply Voltage | 24 V dc |
| Размеры рамы,мм | 80×80 |
| Рабочее напряжение,В | 24 |
| Питание | 3pin |
| Product Category | DC Fan |
| Type | Axial |
| Width | 80mm |
| Power consumption | 2.4W |
| Bearing Type | Ball |
| AC or DC Operation | DC |
| Maximum Current | 100mA |
| Sensor Type | Pulse |
| HTS | 8414.59.65.90 |
| Termination Type | Lead Wire |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant with Exemption |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Pressure | 0.193inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Shape | Square |
| Size (mm) | 80 X 80 X 25 |
| Voltage Rating (V) | 24 |
| Power Rating (W) | 2.4 |
| Nominal Speed (r/min) | 3400 |
| Maximum Airflow (CFM) | 42.4 |
| Noise Level (dB) | 34 |
| Bearings | Ball |
| Line Current (A) | 0.1 |
| Operating Input Voltage Range (V) | 12 to 27.6 |
| SVHC | Yes |
| SVHC Exceeds Threshold | Yes |
Детали
| Бренд | Sanyo Denki |
|---|
