Sanyo Denki
8008679258 9WPA0624P4G001, Fan Tubeaxial 24VDC Square — 60mm L x 60mm H Ball 53.7 CFM (1.50m³/min) 4 Wire Leads Hirschmann
11430,00 ₽
Описание
The Sanyo Denki 9WA 60 W Splash Proof Fan delivers a maximum airflow of 1.52 m3/min and a maximum static pressure of 357 Pa, PWM control function enables the control of fan speed, contributing to lowering noise and improving energy efficiency of devices.
| Air Flow | 53.7cfm |
| Series | 9WPA Type |
| Размеры рамы,мм | 60×60 |
| Рабочее напряжение,В | 24 |
| Питание | 4pin |
| Factory Pack Quantity | 80 |
| ECCN | EAR99 |
| HTSUS | 8414596590 |
| RoHS Status | RoHS Compliant |
| Features | Pulse Sensor, Splash Proof, Dust Proof |
| Airflow | 53.7 CFM(1.52 m3/min) |
| Current Type | DC |
| IP Rating | IP68 |
| Noise | 56 dBA |
| Operating Supply Voltage | 24 VDC |
| Power Rating | 11.04 W |
| Termination Style | Wire Leads-4 |
| Type | Axial |
| Width | 60mm |
| Housing Material | Plastic |
| speed | 12000 RPM |
| Bearing Type | Ball |
| Pressure Type | 1.44 in H2O |
| Tradename | San Ace 60W |
| AC or DC Operation | DC |
| Life | 70000 Hour |
| Size | 60 mm x 60 mm x 25 mm |
Детали
| Бренд | Sanyo Denki |
|---|
