8031169799 CFM-9238BF68-280-585-22, DC Fans 92 mm square, 38 mm, 24 Vdc, ball, 8000 RPM, 108.9 CFM, TS/PWM, IP68 Hirschmann
6940,00 ₽
Описание
CFM IP68 Rated DC Axial Fans Same Sky CFM IP68 Rated DC Axial Fans offer a dual ball-bearing system with multiple speed options. These axial fans feature PWM/tachometer signals, polarity protection, and auto-restart protection. The DC axial fans operate from a -10°C to 70°C temperature range and a 12VDC or 24VDC rated voltage. These DC fans offer 10MΩ insulation resistance and 5mA dielectric strength and are RoHS compliant.
| Потребляемая мощность, Вт | 16.8 |
| Тип подшипника | Ball |
| Размеры рамы,мм | 92×92 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 38 |
| Brand | Same Sky |
| Factory Pack Quantity | 50 |
| Manufacturer | Same Sky |
| Product Category | DC Fans |
| Product Type | DC Fans |
| Subcategory | Fans, Blowers & Accessories |
| Features | Dual Ball Bearing, 4 Pole DC Brushless Motor, Tachometer Signal/PWM Control Signal |
| Current Type | DC |
| IP Rating | IP68 |
| Termination Style | Wire Leads |
| Type | DC Axial Fan |
| Housing Material | Polybutylene Terephthalate(PBT) |
| Частота вращения,об./мин. | 8000 |
| Производительность,м.куб./мин. | 108.9 |
| Шум, дБA | 58.5 |
| Life | 70000 Hour |
| Lead Length | 300 mm |
| Size | 92 mm x 92 mm x 38 mm |
Детали
| Бренд | Same Sky |
|---|
