Sanyo Denki
8049705617 Вентилятор Sanyo Denki San Ace 80W 9WL0824P4J001 24V DC 0.28A 80X25 4pin Hirschmann
7790,00 ₽
Описание
San Ace 9WL series fans have IP68 waterproof protection also protecting against dust. These fans are ideal for equipment that operates without maintenance for long durations.
| Вес, г | 150 |
| Air Flow | 124.2m³/h |
| Mounting | Flange Mount |
| Noise Level | 49dB |
| Special Features | Long Life|Low Power Consumption|High Air Flow|High Static Pressure |
| Supply Voltage | 24 V dc |
| Product Category | DC Fan |
| IP Rating | IP68 |
| Type | Axial |
| Width | 80mm |
| Power consumption | 6.72W |
| Bearing Type | Ball |
| AC or DC Operation | DC |
| Maximum Current | 280mA |
| Fan Speed | 7400rpm |
| Sensor Type | PWM, Tachometer |
| HTS | 8414.59.15.00 |
| Termination Type | Lead Wire |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | 4A994 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 70 |
| Maximum Pressure | 0.71inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Shape | Square |
| Size (mm) | 80 X 80 X 25.2 |
| Voltage Rating (V) | 24 |
| Power Rating (W) | 6.72 |
| Nominal Speed (r/min) | 7400 |
| Maximum Airflow (CFM) | 73 |
| Noise Level (dB) | 49 |
| Bearings | Ball |
| Line Current (A) | 0.28 |
| Operating Input Voltage Range (V) | 21.6 to 26.4 |
Детали
| Бренд | Sanyo Denki |
|---|
