Orion Fans
8005183859 OA172SAPL-22-1TB, AC Fans Axial Fan, 150x172x38mm, 230VAC, 211CFM, 28W, 58dBA, 3400RPM, Ball, Terminals Hirschmann
9900,00 ₽
Описание
Fan Tubeaxial 230VAC Rectangular/Rounded — 172mm L x 150mm H Ball 228.0 CFM (6.38mВі/min) 2 Terminals
| Вес, г | 726 |
| Потребляемая мощность, Вт | 28 |
| Fan Type | Tubeaxial |
| Series | OA172SAPL-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 150×172 |
| Рабочее напряжение,В | 230 |
| Толщина,мм | 38 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 60000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Aluminum |
| Operating Temperature | -4 ~ 176В°F(-20 ~ 80В°C) |
| Size / Dimension | Rectangular/Rounded-172mm L x 150mm H |
| Termination | 2 Terminals |
| Width | 38.50mm |
| Static Pressure | 0.87 in H2O(216.7 Pa) |
| Частота вращения,об./мин. | 3400 |
| Производительность,м.куб./мин. | 228 |
| Шум, дБA | 58 |
| Voltage Range | 160 ~ 260VAC |
Детали
| Бренд | Orion Fans |
|---|
