8006477482 OA172SAPL-22-1TBIP55, AC Fans Axial Fan, 150x172x38mm, 230VAC, 228CFM, 28W, 58dBA, Ball, Terminal, IP55 Hirschmann
11230,00 ₽
Описание
Fan Tubeaxial 230VAC Rectangular/Rounded — 172mm L x 150mm H Ball 228.0 CFM (6.38mВі/min) 2 Terminals
| Потребляемая мощность, Вт | 28 |
| Fan Type | Tubeaxial |
| Mounting | Flange Mount |
| Noise Level | 58 dB |
| Series | OA172SAPL-> |
| Special Features | High Speed |
| Тип подшипника | Ball |
| Размеры рамы,мм | 150×172 |
| Рабочее напряжение,В | 230 |
| Толщина,мм | 38 |
| Product Category | AC Fan |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Box |
| REACH Status | REACH Unaffected |
| RoHS Status | ROHS3 Compliant |
| Power Rating | 28 W |
| Type | Axial |
| Approval Agency | cURus, TUV |
| Lifetime @ Temp. | 60000 Hrs @ 40В°C |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Aluminum |
| Operating Temperature | -4 ~ 176В°F(-20 ~ 80В°C) |
| Size / Dimension | Rectangular/Rounded-172mm L x 150mm H |
| Termination | 2 Terminals |
| Width | 38.00mm |
| Category | AC Fan |
| COO | TW |
| Housing Material | Die-Cast Aluminum |
| Maximum Airflow | 228 CFM |
| RoHS | Yes |
| Supplier Standard Pack | 1 |
| Voltage Rating | 230 V |
| Единица измерения | шт |
| Ingress Protection | IP55-Dust Protected, Water Resistant |
| Static Pressure | 0.87 in H2O(216.7 Pa) |
| Частота вращения,об./мин. | 3400 |
| Производительность,м.куб./мин. | 228 |
| Шум, дБA | 58 |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| Video File | Harsh Environment Fans |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 80 |
| Maximum Pressure | 0.87inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Protection | IP55 |
| Shape | Rectangular/Round |
| Voltage Range | 160 ~ 260VAC |
| Size (Metric) (mm) | 172 X 150 X 38 |
| Voltage Rating (V) | 230 |
| Power Rating (W) | 28 |
| Nominal Speed (r/min) | 3400 |
| Maximum Airflow (CFM) | 228 |
| Noise Level (dB) | 58 |
| Bearings | Ball |
| Operating Input Voltage Range (V) | 160 to 260 |
Детали
| Бренд | Orion Fans |
|---|
