Mechatronics
8005967734 UF15PC12/23-BWHR, FAN 172X150X51MM 115/230VAC Hirschmann
12730,00 ₽
Описание
Fan Tubeaxial 115/230VAC Rectangular/Rounded — 172mm L x 150mm H Ball 226.0 CFM (6.33mВі/min) 4 Wire Leads
| Потребляемая мощность, Вт | 29 |
| Fan Type | Tubeaxial |
| Series | UF15PC-> |
| Тип подшипника | Ball |
| Размеры рамы,мм | 172×150 |
| Рабочее напряжение,В | 115 |
| ECCN | EAR99 |
| HTSUS | 8414.59.6590 |
| Moisture Sensitivity Level (MSL) | 1(Unlimited) |
| Package | Bulk |
| RoHS Status | RoHS Compliant |
| Features | Dual Voltage, Permanent Split Capacitor Motor, The |
| Approval Agency | CE, cUL, TUV, UL |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Aluminum |
| Operating Temperature | -40 ~ 158В°F(-40 ~ 70В°C) |
| Size / Dimension | Rectangular/Rounded-172mm L x 150mm H |
| Termination | 4 Wire Leads |
| Weight | 1.8 lbs(816.5 g) |
| Width | 51.00mm |
| Current Rating (Amps) | 0.120A/0.250A |
| Static Pressure | 0.79 in H2O(196.8 Pa) |
| Частота вращения,об./мин. | 3400 |
| Производительность,м.куб./мин. | 226 |
| Шум, дБA | 58 |
Детали
| Бренд | Mechatronics |
|---|
