Orion Fans
8006812050 OA2547AN-22-1WB1856, AC Fans Tubeaxial Fan, 254x254x89mm, 230VAC, 1000CFM, 105W, 70dBA, Ball, Wire, IP56 Hirschmann
23910,00 ₽
Описание
Fan Tubeaxial 230VAC Round — 254mm Dia Ball 1000.0 CFM (28.00m³/min) 2 Wire Leads
| Air Flow | 1000 CFM(28.00m³/min) |
| Fan Type | Tubeaxial |
| Размеры рамы,мм | 254×254 |
| Рабочее напряжение,В | 230 |
| ECCN | EAR99 |
| Features | Capacitor, Thermal Overload Protector(TOP) |
| Noise | 70.0dB |
| Approval Agency | cURus, TUV |
| Operating Temperature | -22 ~ 176°F(-30 ~ 80°C) |
| Termination | 2 Wire Leads |
| Width | 89.00mm |
| Category | ACFan |
| COO | TW |
| RoHS | Yes |
| Ingress Protection | IP56-Dust Protected, Water Resistant |
| Static Pressure | 0.6 in H2O(149.5 Pa) |
| Bearing Type | Ball |
| Power (Watts) | 105W |
| RPM | 3250 RPM |
| Voltage — Rated | 230VAC |
| HTS | 8414596590 |
| UnitofMeasure | PerEach |
Детали
| Бренд | Orion Fans |
|---|
