Orion Fans
8005961224 OD1238-24LB, FAN AXIAL 120X38.5MM 24VDC WIRE Hirschmann
6860,00 ₽
Описание
DC Fan Axial Ball Bearing 24V 16V to 26V 89.5CFM 35.6dB 120 X 120 X 38mm Low Speed
| Mounting | Flange Mount |
| Special Features | Low Speed |
| Размеры рамы,мм | 120×120 |
| Рабочее напряжение,В | 24 |
| Толщина,мм | 38 |
| Питание | 2pin |
| Product Category | DC Fan |
| ECCN | EAR99 |
| Type | Axial |
| COO | TW |
| RoHS | Yes |
| Supplier Standard Pack | 1 |
| Единица измерения | шт |
| Automotive | Unknown |
| Part Status | Active |
| PPAP | Unknown |
| ECCN (US) | EAR99 |
| EU RoHS | Compliant |
| Maximum Operating Temperature (°C) | 65 |
| Maximum Pressure | 0.316inH2O |
| Minimum Operating Temperature (°C) | -20 |
| Protection | Auto Restart|Polarity |
| Shape | Square |
| Size (mm) | 120 X 120 X 38 |
| Voltage Rating (V) | 24 |
| Power Rating (W) | 4 |
| Nominal Speed (r/min) | 1975 |
| Maximum Airflow (CFM) | 89.5 |
| Noise Level (dB) | 35.6 |
| Bearings | Ball |
| Line Current (A) | 0.15 |
| Operating Input Voltage Range (V) | 16 to 26 |
Детали
| Бренд | Orion Fans |
|---|
