8005963971 G4020H24B-RSR, Fan Tubeaxial 24VDC Square — 40mm L x 40mm H Ball 11.0 CFM (0.308m³/min) 2 Wire Leads Hirschmann
2500,00 ₽
Описание
Fan Tubeaxial 24VDC Square — 40mm L x 40mm H Ball 11.0 CFM (0.308m³/min) 2 Wire Leads
| Вес, г | 28 |
| Air Flow | 11 CFM(0.308m³/min) |
| Fan Type | Tubeaxial |
| Series | G4020 |
| Размеры рамы,мм | 40×40 |
| Рабочее напряжение,В | 24 |
| Питание | 2pin |
| Manufacturer | Mechatronics Fan Group |
| Features | Thermal Overload Protector(TOP) |
| Noise | 29.0dB(A) |
| Approval Agency | CE, cUL, TUV, UL |
| Material — Blade | Polybutylene Terephthalate(PBT) |
| Material — Frame | Polybutylene Terephthalate(PBT) |
| Size / Dimension | Square-40mm L x 40mm H |
| Termination | 2 Wire Leads |
| Weight | 0.062 lb(28.12g) |
| Width | 20.00mm |
| COO | JP |
| RoHS | Yes |
| Supplier Standard Pack | 50 |
| Единица измерения | шт |
| Current Rating (Amps) | 0.080A |
| Static Pressure | 0.2 in H2O(49.8 Pa) |
| Bearing Type | Ball |
| RPM | 7000 RPM |
| Voltage — Rated | 24VDC |
| Part Status | Active |
| Alias/AKA | 130-0020-8-71 |
| Approvals | CE, cUL, TUV, UL |
Детали
| Бренд | Mechatronics |
|---|
